Engine: 6.2L 2-Valve SOHC EFI NA V8 (Flex-Fuel)
Transmission: TorqShift 6-Speed Automatic -inc: SelectShift, range select and tow/haul feature
3.73 Axle Ratio
GVWR: 13,700 lb Payload Package
50-State Emissions System
Transmission w/Oil Cooler
Rear-Wheel Drive
72-Amp/Hr 650CCA Maintenance-Free Battery w/Run Down Protection
157 Amp Alternator
Towing w/Harness
7872# Maximum Payload
HD Shock Absorbers
Front And Rear Anti-Roll Bars
Firm Suspension
Hydraulic Power-Assist Steering
40 Gal. Fuel Tank
Single Stainless Steel Exhaust
Front Suspension w/Coil Springs
Leaf Rear Suspension w/Leaf Springs
4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs
Upfitter Switches

Exterior

Wheels: 17" Argent Painted Steel -inc: Hub covers and center ornaments not included
Tires: LT245/75Rx17E BSW AS
Clearcoat Paint
Black Front Bumper w/2 Tow Hooks
Black Side Windows Trim and Black Front Windshield Trim
Black Door Handles
Black Manual Side Mirrors w/Manual Folding
Manual Extendable Trailer Style Mirrors
Fixed Rear Window
Light Tinted Glass
Variable Intermittent Wipers
Fully Galvanized Steel Panels
Black Grille
Front License Plate Bracket
Aero-Composite Halogen Headlamps
Cab Clearance Lights

Entertainment

Radio: AM/FM Stereo w/Digital Clock -inc: 2 speakers
Fixed Antenna

Interior

4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
Manual Tilt/Telescoping Steering Column
Gauges -inc: Speedometer, Odometer, Oil Pressure, Engine Coolant Temp, Tachometer, Transmission Fluid Temp, Engine Hour Meter and Trip Odometer
Front Cupholder
Manual Air Conditioning
Glove Box
Interior Trim -inc: Chrome Interior Accents
Full Cloth Headliner
Urethane Gear Shift Knob
HD Vinyl 40/20/40 Split Bench Seat -inc: center armrest, cupholder and storage
Day-Night Rearview Mirror
Passenger Visor Vanity Mirror
2 12V DC Power Outlets
Front Map Lights
Fade-To-Off Interior Lighting
Full Vinyl/Rubber Floor Covering
Underhood Lights
Instrument Panel Bin and Dashboard Storage
Manual 1st Row Windows
Systems Monitor
Outside Temp Gauge
Analog Display
Manual Adjustable Front Head Restraints

Safety

Driveline Traction Control
Side Impact Beams
Dual Stage Driver And Passenger Seat-Mounted Side Airbags
Dual Stage Driver And Passenger Front Airbags w/Passenger Off Switch
Curtain 1st Row Airbags
Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters

Ford Super Duty F-350 DRW 2WD Reg Cab 141" WB 60" CA XL
Available Options

Engine

ENGINE: 6.2L 2-VALVE SOHC EFI NA V8 (996) - Standard
ENGINE: 6.7L POWER STROKE V8 TURBO DIESEL B20 (99T)

Transmission

TRANSMISSION: TORQSHIFT 6-SPEED AUTOMATIC (44P) - Standard
TRANSMISSION: TORQSHIFT 6-SPEED AUTOMATIC (6.7L) -inc: SelectShift (44W)

Option Package

ORDER CODE 640A (640A)

Axle Ratio

3.73 AXLE RATIO (X37) - Standard
LIMITED SLIP W/4.10 AXLE RATIO (X4N)
LIMITED SLIP W/4.30 AXLE RATIO (X4L)
LIMITED SLIP W/4.10 AXLE RATIO (WIDE TRACK) (X4W)

Wheels

WHEELS: 17" ARGENT PAINTED STEEL (64K) - Standard
WHEELS: 17" FORGED POLISHED ALUMINUM (64J)

Tires

TIRES: LT245/75RX17E BSW (TBK) - Standard
TIRES: LT245/75RX17E BSW (TBM)

Primary Paint

SHADOW BLACK (G1)
CARIBOU METALLIC (H5)
GREEN GEM METALLIC (W6)
BLUE JEANS METALLIC (N1)
MAGNETIC METALLIC (J7)
OXFORD WHITE (Z1)
INGOT SILVER METALLIC (UX)
RACE RED (PQ)

Paint Scheme

STANDARD PAINT (undefined)

Seat Type

STEEL, HD VINYL 40/20/40 SPLIT BENCH SEAT -inc: center armrest, cupholder and storage (AS)
STEEL, CLOTH 40/20/40 SPLIT BENCH SEAT -inc: center armrest, cupholder and storage (1S)
STEEL, CLOTH FRONT SEATS (2S)
STEEL, VINYL 40/MINI-CONSOLE/40 FRONT SEATS -inc: Mini-Console (LS)

Additional Equipment

XL DECOR GROUP (17F)
POWER EQUIPMENT GROUP (90L)
AMBULANCE PREP PACKAGE -inc: max front springs/GAWR rating for configuration selected, Incomplete vehicle package - requires further manufacture and certification by a final stage manufacturer, Ford vehicles are suitable for producing ambulances only if equipped w/the Ford Ambulance Prep Package, In addition, Ford urges ambulance manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual and the Ford Truck Body Builders Layout Book (and pertinent supplements), Using a Ford vehicle without the Ford Ambulance Prep Package to produce an ambulance voids the Ford warranty, NOTE: Stationary Elevated Idle Control (SEIC) has been integrated into the engine control module, Limited Slip w/4.10 Axle Ratio (Wide Track), Dual Alternators (Total 357-Amps), Operator Commanded Regeneration (OCR) (47A)
AMBULANCE PREP PKG W/SPECIAL EMISSIONS -inc: max front springs/GAWR rating for configuration selected, Incomplete vehicle package - requires further manufacture and certification by a final stage manufacturer, Ford vehicles are suitable for producing ambulances w/special emissions only if equipped w/the Ford Ambulance Prep Package w/EPA Special Emergency Vehicle Emissions, In addition, Ford urges ambulance manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual and the Ford Truck Body Builders Layout Book (and pertinent supplements), Using a Ford vehicle without the Ford Ambulance Package w/EPA Special Emergency Vehicle Emissions to produce an ambulance w/special emissions voids the Ford warranty, NOTE 1: Stationary Elevated Idle Control (SEIC) has been integrated into the engine control module, NOTE 2: Engine calibration significantly reduces the possibility of depower mode when in stationary PTO operation, NOTE 3: Allows operator commanded regen down to 30% of DPF filter full, instead of 100%, NOTE 4: Must meet the definition of an Emergency Vehicle, an Ambulance or Fire Truck per 40 CFR 86.1803.01 in the Federal Register, Limited Slip w/4.10 Axle Ratio (Wide Track), Dual Alternators (Total 357-Amps), Operator Commanded Regeneration (OCR) (47L)
FIRE/RESCUE PREP PACKAGE -inc: max front springs/GAWR rating for configuration selected, Incomplete vehicle package - requires further manufacture and certification by a final stage manufacturer, Ford urges Fire/Rescue Vehicle manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual and the Ford Truck Body Builders Layout Book (and pertinent supplements), NOTE 1: Stationary Elevated Idle Control (SEIC) has been integrated into the engine control module, NOTE 2: Engine calibration significantly reduces the possibility of depower mode when in stationary PTO operation, NOTE 3: Operator commanded regen down to 30% of DPF filter full, instead of 100%, NOTE 4: Must meet the definition of an Emergency Vehicle, an Ambulance or Fire Truck per 40 CFR 86.1803.01 in the Federal Register, Dual Alternators (Total 357-Amps), Operator Commanded Regeneration (OCR) (47J)
XL VALUE PACKAGE (96V)
XL APPEARANCE PACKAGE (96P)
TRANSMISSION POWER TAKE-OFF PROVISION -inc: transmission mounted live drive and stationary mode PTO (62R)
ENGINE IDLE SHUTDOWN (63T)
OPERATOR COMMANDED REGENERATION (OCR) (98R)
DUAL ALTERNATORS (TOTAL 357-AMPS) (67A)
EXTRA 200-AMP ALTERNATOR (67D)
ENGINE BLOCK HEATER (41H)
TRAILER TOW PACKAGE -inc: aftermarket trailer brake wiring kit, NOTE: Salesperson's Source Book or Ford RV Trailer Towing Guide should be consulted for specific trailer towing or camper limits and corresponding required equipment, axle ratios and model availability (531)
TRAILER BRAKE CONTROLLER (52B)
GVWR: 14,000 LB PAYLOAD PACKAGE (undefined)
FRONT SUSPENSION PACKAGE (67H)
EXTRA HEAVY-SERVICE SUSPENSION PACKAGE -inc: pre-selected extra heavy-service front springs (see Order Guide Supplemental Reference for springs/FGAWR of specific vehicle configurations), Recommended only on vehicles which will permanently utilize aftermarket equipment such as heavy-duty winches, brush guards or other apparatus which loads the front axle to the specified Gross Axle Weight Rating (GAWR), NOTE 1: May result in a deterioration of ride quality, NOTE 2: Vehicle ride height will increase w/the addition of this package (67X)
DUAL DIESEL FUEL TANKS -inc: Combines 40 gallon aft-of-axle and 28 gallon mid ship tank (65C)
28 GALLON MID SHIP FUEL TANK (65M)
STAINLESS STEEL WHEEL COVERS (945)
SPARE TIRE, WHEEL, & JACK (512)
SPARE TIRE & WHEEL DELETE (51D)
MANUAL SLIDING REAR WINDOW W/PRIVACY GLASS (433)
6" ANGULAR BLACK MOLDED-IN-COLOR RUNNING BOARDS (18B)
FRONT SPLASH GUARDS/MUD FLAPS (PRE INSTALLED) -inc: Custom accessory (61S)
CENTER STOP LAMP (CHMSL) (59H)
AMBER LED WARNING STROBES (PRE INSTALLED) -inc: Custom accessory, center high-mounted stop light bar and 2 hood mounted lights (87S)
CNG/PROPANE GASEOUS ENGINE PREP PACKAGE (98F)
4-TON HYDRAULIC JACK (61J)
DELETE (58Y)
RADIO: AM/FM STEREO/SINGLE CD/MP3 (585)
STEERING WHEEL AUDIO CONTROLS (62D)
SYNC W/MYFORD (91M)
STEERING WHEEL-MOUNTED CRUISE CONTROL (525)
AIR CONDITIONING DELETE (572)
RAPID-HEAT SUPPLEMENTAL CAB HEATER (41A)
REAR VIEW CAMERA & PREP KIT (76D)
FORD TELEMATICS POWERED BY TELOGIS (87T)
EXTERIOR BACKUP ALARM (PRE INSTALLED) -inc: Custom accessory, (76C)
SPEED LIMITATION - 65 MPH GOVERNED TOP SPEED (926)
SPEED LIMITATION - 75 MPH GOVERNED TOP SPEED (927)
DRIVER/PASS SIDE DELETE (556)
FRONTAL PASS & SIDE DELETE (557)
FLEET ADVERTISING CREDIT (undefined)
DAYTIME RUNNING LAMPS (DRL) (942)
COV REQUIRED (79V)
PRICED DORA (C09)
REMOTE START SYSTEM (76S)

Ship Thru Codes

SHIP-THRU: KNAPHEIDE TRUCK EQUIPMENT (31V)
SHIP-THRU: L&Z CO. (31E)
SHIP-THRU: MANNING LIGHT TRUCK EQUIPMENT (31M)
SHIP-THRU: PALFLEET TRUCK EQUIPMENT (31T)
SHIP-THRU: READING EQUIPMENT & DISTRIBUTION (31B)
SHIP-THRU: ROUSH INDUSTRIES (31P)
SHIP-THRU: READING EQUIPMENT (31S)
SHIP-THRU: ALTEC (31A)
SHIP-THRU: IMPCO (31Q)
SHIP-THRU: ZORESCO EQUIPMENT (31C)
SHIP-THRU: LOUISVILLE TRUCK EQUIPMENT (31L)
SHIP-THRU: MONROE TRUCK EQUIPMENT (31N)
SHIP-THRU: NBC TRUCK EQUIPMENT (31G)
SHIP-THRU: VENCHURS VEHICLE SYSTEM (31F)
BUILT: KENTUCKY TRUCK PLANT (D9E)

Ford Super Duty F-350 DRW 2WD Reg Cab 141" WB 60" CA XL
Warranties

Basic Years - 3
Basic Miles/km - 36,000
Drivetrain Years - 5
Drivetrain Miles/km - 60,000
Corrosion Years - 5
Corrosion Miles/km - Unlimited
Roadside Assistance Years - 5
Roadside Assistance Miles/km - 60,000

Ford Super Duty F-350 DRW 2WD Reg Cab 141" WB 60" CA XL
Technical Specifications

Summary

Vehicle Name - Ford Super Duty F-350 DRW
Body Style - SD Regular Cab

Transmission

Drivetrain - Rear Wheel Drive
Trans Order Code - 44W (44W), 44P
Trans Type - 6
Trans Description Cont. - Automatic w/OD
Trans Description Cont. Again -
First Gear Ratio (:1) - 3.97
Second Gear Ratio (:1) - 2.32
Third Gear Ratio (:1) - 1.52
Fourth Gear Ratio (:1) - 1.15
Fifth Gear Ratio (:1) - 0.86
Sixth Gear Ratio (:1) - 0.67
Reverse Ratio (:1) - 3.13
Trans Power Take Off - Yes (62R)
Trans PTO Access - Yes (62R), No
Transfer Case Power Take Off - Yes (62R), No

Interior Dimensions

Passenger Capacity - 2 (LS,2S), 3
Front Head Room - 40.7 in
Front Leg Room - 41.1 in
Front Shoulder Room - 68 in
Front Hip Room - 67.6 in
Second Head Room -
Second Leg Room -
Second Shoulder Room -
Second Hip Room -

Weight Information

Gross Axle Wt Rating - Front - 4250 lbs
Gross Axle Wt Rating - Rear - 9750 lbs
Curb Weight - Front - 3376 lbs
Curb Weight - Rear - 2634 lbs
Gross Vehicle Weight Rating Cap - 14000 lbs (-NONGV), 13700 lbs
Gross Combined Wt Rating - 19500 lbs

Trailering

Dead Weight Hitch - Max Trailer Wt. - 12400 lbs
Dead Weight Hitch - Max Tongue Wt. - 1240 lbs
Wt Distributing Hitch - Max Trailer Wt. - 12400 lbs
Wt Distributing Hitch - Max Tongue Wt. - 1240 lbs
Fifth Wheel Hitch - Max Trailer Wt. - 12400 lbs
Maximum Trailering Capacity - 12400 lbs

Engine

Engine Order Code - 99T (99T), 996
Engine Type - Intercooled Turbo Diesel V-8 (99T), Regular Unleaded V-8
Displacement - 6.7 L/406 (99T), 6.2 L/379
Fuel System - Diesel Direct Injection (99T), Sequential MPI
SAE Net Horsepower @ RPM - 300 @ 2800 (99T), 316 @ 4179
SAE Net Torque @ RPM - 660 @ 1600 (99T), 397 @ 4179
Engine Oil Cooler - None

Electrical

Cold Cranking Amps @ 0° F (Primary) - 750 (99T), 650
Cold Cranking Amps @ 0° F (2nd) - 750 (99T), 650
Maximum Alternator Capacity (amps) - 357 (67A-R,67A-F), 200 (67D-R,67D-F), 157

Suspension

Suspension Type - Front - Other
Suspension Type - Rear - Leaf
Spring Capacity - Front - 4250 lbs
Spring Capacity - Rear - 9750 lbs
Axle Type - Front - Independent
Axle Type - Rear - Rigid Axle
Axle Capacity - Front - 5250 lbs
Axle Capacity - Rear - 9750 lbs
Axle Ratio (:1) - Front - 4.10 (X4N,X4W), 4.30 (X4L), 3.73
Axle Ratio (:1) - Rear - 4.10 (X4N,X4W), 4.30 (X4L), 3.73

Tires

Front Tire Order Code - TBM (TBM), TBK
Rear Tire Order Code - TBM (TBM), TBK
Spare Tire Order Code - 512 (512)
Front Tire Size - LT245/75SR17
Rear Tire Size - LT245/75SR17
Spare Tire Size - Full-Size (512)
Front Tire Capacity - 6390 lbs (64J), 5820 lbs
Rear Tire Capacity - 12780 lbs (64J), 11640 lbs
Revolutions/Mile @ 45 mph - Front - 663 Rev/Mile (TBM), 660 Rev/Mile
Revolutions/Mile @ 45 mph - Rear - 663 Rev/Mile (TBM), 660 Rev/Mile

Wheels

Front Wheel Size - 17 X 6.5 in
Rear Wheel Size - 17 X 6.5 in
Spare Wheel Size - Full-Size in (512)
Front Wheel Material - Forged Aluminum (64J), Steel
Rear Wheel Material - Forged Aluminum (64J), Steel
Spare Wheel Material - Steel (512)

Steering

Steering Type - Re-Circulating Ball
Turning Diameter - Curb to Curb - 48.9 ft

Brakes

Brake ABS System - 4-Wheel
Brake ABS System (Second Line) - 4-Wheel
Disc - Front (Yes or ) - Yes
Disc - Rear (Yes or ) - Yes
Front Brake Rotor Diam x Thickness - 14.3 in
Rear Brake Rotor Diam x Thickness - 14.3 in
Drum - Rear (Yes or ) -
Rear Drum Diam x Width -

Fuel Tank

Fuel Tank Capacity, Approx - 28 gal (65M), 40 gal
Aux Fuel Tank Capacity, Approx - 28 gal (65C)
Fuel Tank Location - Midship
Aux Fuel Tank Location - Midship

Exterior Dimensions

Wheelbase - 141 in
Width, Max w/o mirrors - 95.2 in (47A), 92.2 in
Height, Overall - 77.3 in
Cab to Axle - 60 in
Ground Clearance, Front - 8.2 in
Ground Clearance, Rear - 8.2 in
Ground to Top of Load Floor -

Cargo Area Dimensions

Cargo Box Length @ Floor -
Cargo Box Width @ Top, Rear -
Cargo Box Width @ Floor -
Cargo Box Width @ Wheelhousings -
Cargo Box (Area) Height -
Cargo Volume -
