Engine: 2.0L GDI I-4 Gas -inc: auto start/stop system and EcoMode
Transmission: 8-Speed SelectShift Automatic
3.80 Axle Ratio
GVWR: TBD
50-State Emissions System
Transmission w/SelectShift Sequential Shift Control
Front-Wheel Drive
80-Amp/Hr 800CCA Maintenance-Free Battery w/Run Down Protection
220 Amp Alternator
1250# Maximum Payload
Gas-Pressurized Shock Absorbers
Front And Rear Anti-Roll Bars
Electric Power-Assist Steering
15.8 Gal. Fuel Tank
Single Stainless Steel Exhaust
Strut Front Suspension w/Coil Springs
Torsion Beam Rear Suspension w/Coil Springs
4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control

Exterior

Wheels: 16" Sparkle Silver-Painted Steel -inc: full wheel covers (non-locking lug nuts)
Tires: 215/55R16 97H XL AS
Steel Spare Wheel
Full-Size Spare Tire Stored Underbody w/Crankdown
Clearcoat Paint
Black Front Bumper
Black Rear Bumper
Black Side Windows Trim and Black Front Windshield Trim
Black Bodyside Moldings
Black Door Handles
Black Manual Side Mirrors w/Convex Spotter and Manual Folding
Fixed Rear Window w/Fixed Interval Wiper and Defroster
Light Tinted Glass
Variable Intermittent Wipers
Fully Galvanized Steel Panels
Black Grille
Sliding Rear Doors
Split Swing-Out Rear Cargo Access
Tailgate/Rear Door Lock Included w/Power Door Locks
Perimeter/Approach Lights
Aero-Composite Halogen Daytime Running Headlamps

Entertainment

Radio: AM/FM w/Bluetooth -inc: FordPass connect, 4.2" LCD multi-function display (MFD) screen, 1 USB port and 4-speaker system (2 front door and 2 rear door speakers)
Radio w/Seek-Scan, Clock, Speed Compensated Volume Control, Aux Audio Input Jack, Radio Data System and SYNC External Memory Control
Integrated Roof Antenna
Streaming Audio

Interior

Front Seats w/Vinyl Back Material and Manual Driver Lumbar
2-Way Driver Seat -inc: Manual Lumbar Support
Passenger Seat
Bucket Folding Bucket Front Facing Fold Forward Seatback Vinyl Rear Seat
Front Center Armrest w/Storage and Rear Seat Mounted Armrest Outboard Only
Manual Tilt/Telescoping Steering Column
Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Tachometer, Trip Odometer and Trip Computer
Power Rear Windows and Fixed 3rd Row Windows
FordPass Connect 4G LTE WiFi Mobile Hotspot Internet Access
Fixed Bucket Bucket Vinyl 3rd Row Seat Front, 2 Manual and Adjustable Head Restraints
Front Cupholder
Rear Cupholder
3 12V DC Power Outlets
Remote Keyless Entry w/Integrated Key Transmitter and Illuminated Entry
Cruise Control w/Steering Wheel Controls
Dual Zone Front Automatic Air Conditioning
Rear HVAC w/Separate Controls
Glove Box
Driver Foot Rest
Full Cloth Headliner
Cloth Door Trim Insert
Urethane Gear Shifter Material
Vinyl Front Bucket Seats -inc: 6-way manual driver seat (fore/aft, up/down & lever recline) w/manual lumbar and 4-way manual passenger seat (fore/aft & lever recline) w/fold-flat back
Day-Night Rearview Mirror
Full Floor Console w/Storage, Full Overhead Console w/Storage, 3 12V DC Power Outlets and 1 AC Power Outlet
Front Map Lights
Delay Off Interior Lighting
Full Vinyl/Rubber Floor Covering
Vinyl/Rubber Floor Trim
Cargo Net
Cargo Space Lights
FOB Controls -inc: Cargo Access
Smart Device Remote Engine Start
Driver / Passenger And Rear Door Bins
Delayed Accessory Power
Power Door Locks w/Autolock Feature
Power 1st Row Windows w/Driver 1-Touch Down
Systems Monitor
Redundant Digital Speedometer
Trip Computer
Outside Temp Gauge
Analog Display
Manual w/Tilt (driver Only) Front Head Restraints and Manual Adjustable Rear Head Restraints
1 Seatback Storage Pocket
Securilock Anti-Theft Ignition (pats) Engine Immobilizer
3 12V DC Power Outlets and 1 AC Power Outlet

Safety

AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
ABS And Driveline Traction Control
Side Impact Beams
Dual Stage Driver And Passenger Seat-Mounted Side Airbags
Rear Parking Sensors
Forward Collision Warning
Low Tire Pressure Warning
Dual Stage Driver And Passenger Front Airbags
Airbag Occupancy Sensor
Rear Child Safety Locks
Safety Canopy System Curtain 1st, 2nd And 3rd Row Airbags
Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners
Back-Up Camera

Ford Transit Connect Wagon XL LWB w/Rear Symmetrical Doors
Available Options

Engine

ENGINE: 2.0L GDI I-4 GAS -inc: auto start/stop system and EcoMode (992) - Standard
ENGINE: 1.5L ECOBLUE TC DI DIESEL (99F)
ENGINE: 2.5L IVCT I-4 GAS -inc: standard duty battery (60amp-590CCA), 3.21 Axle Ratio (Fleet) (997)

Transmission

TRANSMISSION: 8-SPEED SELECTSHIFT AUTOMATIC (448) - Standard
TRANSMISSION: 6-SPEED SELECTSHIFT AUTO (446)

Option Package

ORDER CODE 200A (200A)

Axle Ratio

3.80 AXLE RATIO (undefined) - Standard
3.21 AXLE RATIO (undefined)

Wheels

WHEELS: 16" 5-SPK SPARKLE SILVER-PNTED ALUM ALLOY -inc: locking wheel lug nuts (64F)
WHEELS: 16" 5-SPOKE PREMIUM LUSTER NICKEL-PAINTED -inc: premium-alloy and locking wheel lugs (648)

Primary Paint

SHADOW BLACK (G1)
RACE RED (PQ)
SILVER (TY)
DARK BLUE (UV)
FROZEN WHITE (Z2)
KAPOOR RED METALLIC (AW)
DIFFUSED SILVER (FK)
BLUE METALLIC (FT)
GUARD METALLIC (HN)
MAGNETIC METALLIC (J7)
SCHOOL BUS YELLOW (BY)

Paint Scheme

STANDARD PAINT (undefined)

Seat Type

EBONY, VINYL FRONT BUCKET SEATS -inc: 6-way manual driver seat (fore/aft, up/down & lever recline) w/manual lumbar and 4-way manual passenger seat (fore/aft & lever recline) w/fold-flat back (SB)
EBONY, CLOTH FRONT BUCKET SEATS -inc: 6-way manual driver seat (fore/aft, up/down & lever recline) w/manual lumbar and 4-way manual passenger seat (fore/aft & lever recline) w/fold-flat back (CB)

Additional Equipment

TAXI PACKAGE -inc: Taxi Upfit Wiring Harness, 4 Manual Keys, 180 Deg, Swing-Out Rear Cargo-Doors, Vinyl Soft Door Armrest, Power 2nd Row Windows, one-touch up/down, Black Power Adjust Heated Mirrors w/Manual Fold, molded-in-color skull caps, 12V Powerpoint in Center Console Front only, Power Front Row Windows, one-touch up/down, Recessed 2nd Row Seat For additional leg room, 2nd Row 3-Passenger 60/40 Bench Seat, 2nd Row A/C Control Button (86T)
DRIVER-ASSIST PACKAGE -inc: Lane-Keeping Aid w/Lane Departure Warning, Auto High Lamps, Driver Impairment Monitor (53C)
FLEX FUEL CAPABILITY (FFV) (98A)
CNG/LPG ENGINE PREP PACKAGE (98G)
HEAVY DUTY BATTERY -inc: (80-amp; 800CCA) (51C)
ENGINE BLOCK HEATER (41H)
65 MPH SPEED LIMITER ENGINE GOVERNOR (916)
75 MPH SPEED LIMITER ENGINE GOVERNOR (917)
TRAILER TOW PACKAGE -inc: trailer tow hitch w/trailer sway control (class 1, 2000 lbs capability, trailer module and 4-pin connector) (53T)
TIRE REPAIR KIT -inc: In lieu of full-size spare wheel (51B)
BLACK POWER ADJUST HEATED MIRRORS W/MANUAL FOLD -inc: molded-in-color skull caps (545)
DARK TINTED GLASS -inc: privacy glass upgrade from normal tinted glass (excludes front row) (924)
QUICKCLEAR ELECTRIC WINDSHIELD DEFROSTER (43W)
FRONT SPLASH GUARDS/MUD FLAPS (96F)
DECAL #1 -inc: Up to 15 sq, ft (16B)
DECAL #2 -inc: Up to 25 sq, ft (16C)
DECAL #3 -inc: Up to 45 sq, ft (16D)
DECAL #4 -inc: Up to 70 sq, ft (16E)
AUTOMATIC HEADLAMPS ON/OFF -inc: Auto-Dimming Rearview Mirror, Rain-Sensing Front Windshield Wipers (94A)
HALOGEN ADAPTIVE CORNERING FOG LAMPS (94F)
ROOF WIRING HOLE (68B)
RADIO: SYNC 3 W/O NAVIGATION -inc: FordPass connect, 6.5" LCD touch screen, AM/FM stereo receiver, SiriusXM satellite radio, 911 Assist, AppLink, Apple CarPlay compatibility, Android Auto compatibility, 2 smart-charging USB ports and 6-speaker system (4 front speakers and 2 rear door speakers), Compass Display, 4-Spoke Steering Wheel, satin chrome shells, SYNC 3 Communications & Entertainment System, VHR, SYNC services, Bluetooth, steering wheel controls and auxiliary input jack (58Z)
RADIO: SYNC 3 RADIO W/NAVIGATION (58Y)
SINGLE-SLOT CD PLAYER (96C)
3RD ROW REAR SEAT DELETE (87D)
2ND ROW 3-PASSENGER 60/40 BENCH SEAT (21M)
KEY FOBS (2 ADDITIONAL) (87R)
CARPET FLOOR COVER -inc: all rows (47H)
FRONT & REAR ALL-WEATHER FLOOR MATS (164)
ROOF RAILS (61B)
ROOF RACK W/CROSS BARS (61X)
VERTICAL CARGO NET KIT (60V)
WIRELESS CHARGING (96B)
UPFITTER WIRING HARNESS (86G)
FORWARD & REVERSE SENSING SYSTEM (76S)
BLIND SPOT INFORMATION SYSTEM (BLIS) (85D)
SMOKER'S PACKAGE (94B)
AIRCRAFT-STYLE MID-VEHICLE OVERHEAD CONSOLE (60M)
MYKEY (87K)
PERIMETER ANTI-THEFT ALARM SYSTEM (65D)
FLEET ADVERTISING CREDIT (undefined)
COV REQUIRED (79V)
PRICED DORA (C09)

Ship Thru Codes

SHIP-THRU: DEJANA - BALTIMORE (31D)
SHIP-THRU: DEJANA/SORTIMO UPFIT - BALTIMORE (31G)
SHIP-THRU: ADRIAN STEEL UPFIT - PORT NEWARK (31P)
SHIP-THRU: LEGGETT & PLATT - BALTIMORE (31F)
SHIP-THRU: CANFIELD FLEET SERVICES (31M)
SHIP-THRU: CVI - OXNARD (31C)
SHIP-THRU: FAPS - PORT NEWARK (31N)
SHIP-THRU: AUTO TRUCK - MAPLE SHADE (31T)
BUILT: VALENCIA PLANT (D91)

Ford Transit Connect Wagon XL LWB w/Rear Symmetrical Doors
Warranties

Basic Years - 3
Basic Miles/km - 36,000
Drivetrain Years - 5
Drivetrain Miles/km - 60,000
Corrosion Years - 5
Corrosion Miles/km - Unlimited
Roadside Assistance Years - 5
Roadside Assistance Miles/km - 60,000

Ford Transit Connect Wagon XL LWB w/Rear Symmetrical Doors
Safety

Male/Female Dummy Note - Male: Average sized adult male dummy in 35-MPH crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs. Female: Small-sized adult female dummy in 35-mph crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs.
Rollover Rating - ★ ★ ★ ★
Rollover Rating Dynamic Test Result - No Tip
Risk of Rollover - 17.90
Rollover Note - Dynamic (moving) test results (Tip or No Tip) and measured rollover-related properties determine vehicle's risk of rollover in single vehicle crash and its rollover rating. The Rollover Resistance Rating utilizes a "fishhook" maneuver which is a series of abrupt turns at varying speeds to see how "top-heavy" a vehicle is.

Ford Transit Connect Wagon XL LWB w/Rear Symmetrical Doors
Technical Specifications

Summary

Vehicle Name - Ford Transit Connect Wagon
Body Style - Passenger Wagon LWB

Transmission

Drivetrain - Front Wheel Drive
Trans Order Code - 448, 446 (446,(448&(99F,(992&98A))))
Trans Type - 8, 6 (446)
Trans Description Cont. - Automatic w/OD
Trans Description Cont. Again -
First Gear Ratio (:1) - 4.69, 4.58 (446)
Second Gear Ratio (:1) - 3.31, 2.96 (446)
Third Gear Ratio (:1) - 3.01, 1.91 (446)
Fourth Gear Ratio (:1) - 1.92, 1.45 (446)
Fifth Gear Ratio (:1) - 1.45, 1.00 (446)
Sixth Gear Ratio (:1) - 1.00, 0.75 (446)
Reverse Ratio (:1) - 2.96, 2.94 (446)
Final Drive Axle Ratio (:1) - 3.80, 3.21 (-NONAX)
Seventh Gear Ratio (:1) - 0.75
Eighth Gear Ratio (:1) - 0.62

Vehicle

EPA Classification - Special Purpose Vehicle 2WD
Model Group -
Vehicle Segment -
Vehicle Type -
Body Cab Style -

Interior Dimensions

Passenger Capacity - 7 (21M), 6, 5 (86T,87D)
Passenger Volume - 167.1 ft³, 120.7 ft³ (86T,87D)
Front Head Room - 46.9 in
Front Leg Room - 42.3 in
Front Shoulder Room - 57.6 in
Front Hip Room - 54.2 in
Second Head Room - 45.7 in
Second Leg Room - 37.6 in
Second Shoulder Room - 58.5 in
Second Hip Room - 58.3 in
Third Head Room - 41.9 in
Third Leg Room - 35 in
Third Shoulder Room - 56.3 in
Third Hip Room - 47 in

Weight Information

Base Curb Weight - 4031 lbs (43W), 4029 lbs (41H,65D,58Y), 4030 lbs (94A,545,85D), 4042 lbs (61B,61X), 4035 lbs (60M), 4053 lbs (53T), 4028 lbs

Mileage

Fuel Economy Est-Combined - - TBD - MPG (448&99F), 22 (Est) MPG (446&997), 26 (Est) MPG
EPA Fuel Economy Est - City - - TBD - MPG (448&99F), 20 (Est) MPG (446&997), 24 (Est) MPG
EPA Fuel Economy Est - Hwy - - TBD - MPG (448&99F), 26 (Est) MPG (446&997), 29 (Est) MPG

Trailering

Dead Weight Hitch - Max Trailer Wt. - 2000 lbs (53T)
Dead Weight Hitch - Max Tongue Wt. - 200 lbs (53T)
Wt Distributing Hitch - Max Trailer Wt. - 2000 lbs (53T)
Wt Distributing Hitch - Max Tongue Wt. - 200 lbs (53T)

Engine

Engine Order Code - 99F (99F), 997 (997), 98A (98A), 992
Engine Type - Turbo Diesel I-4 (99F), Flexible (98A), Regular Unleaded I-4
Displacement - 1.5 L/92 (99F), 2.5 L/152 (997), 2.0 L/122
Fuel System - Diesel Direct Injection (99F), Sequential MPI (997), Gasoline Direct Injection
SAE Net Horsepower @ RPM - 169 @ 6000 (997), 162 @ 6200
SAE Net Torque @ RPM - 171 @ 4500 (997), 144 @ 4500
Engine Displacement Units - 1.5 undefined (99F), 2.0 undefined, 2.0 undefined (992), 2.5 undefined (997)
Engine Camshaft - DOHC undefined, SOHC undefined (99F), DOHC undefined (992), DOHC undefined (997)
Engine Block Type - aluminum undefined, aluminum undefined (992), aluminum undefined (997)
Engine Cylinder Count - 4 undefined (99F), 4 undefined, 4 undefined (992), 4 undefined (997)
Engine Valve Count - 2 undefined (99F), 4 undefined, 4 undefined (992), 4 undefined (997)

Electrical

Cold Cranking Amps @ 0° F (Primary) - 800, 590 (997)
Maximum Alternator Capacity (amps) - 220

Emissions

Tons/yr of CO2 Emissions @ 15K mi/year - - TBD - (448&99F), 8.0 (Est) (446&997), 6.8 (Est)

Suspension

Suspension Type - Front - Strut
Suspension Type - Rear - Torsion Beam
Suspension Type - Front (Cont.) - Strut
Suspension Type - Rear (Cont.) - Torsion Beam

Tires

Front Tire Order Code -
Rear Tire Order Code -
Spare Tire Order Code -
Front Tire Size - P215/55HR16
Rear Tire Size - P215/55HR16
Spare Tire Size - Full-Size

Wheels

Front Wheel Size - 16 X 6.5 in
Rear Wheel Size - 16 X 6.5 in
Spare Wheel Size - Full-Size in
Front Wheel Material - Aluminum (64F,648), Steel
Rear Wheel Material - Aluminum (64F,648), Steel
Spare Wheel Material - Steel

Steering

Steering Type - Rack-Pinion
Turning Diameter - Curb to Curb - 40 ft

Brakes

Brake Type - 4-Wheel Disc
Brake ABS System - 4-Wheel
Disc - Front (Yes or ) - Yes
Disc - Rear (Yes or ) - Yes
Drum - Rear (Yes or ) -

Fuel Tank

Fuel Tank Capacity, Approx - 15.8 gal

Exterior Dimensions

Wheelbase - 120.6 in
Length, Overall - 190 in
Width, Max w/o mirrors - 72.2 in
Height, Overall - 71.6 in
Track Width, Front - 61.4 in
Track Width, Rear - 61.7 in
Min Ground Clearance - 5.7 in
Liftover Height - 22.4 in

Cargo Area Dimensions

Cargo Area Length @ Floor to Seat 1 - 85.6 in
Cargo Area Length @ Floor to Seat 2 - 49.8 in
Cargo Area Length @ Floor to Seat 3 - 16.9 in
Cargo Box Width @ Wheelhousings - 47 in
Cargo Box (Area) Height - 43.3 in
Cargo Volume to Seat 1 - 106 ft³
Cargo Volume to Seat 2 - 60.1 ft³, 58.9 ft³ (86T,87D)
Cargo Volume to Seat 3 - 106 ft³, 58.9 ft³ (86T,87D)
